MODEL NAME
HP Color LaserJet Pro M254nw

PRODUCT NUMBER
T6B59A

ACCESSORIES

HP Color LaserJet Pro M254nw T6B59A); Introductory HP LaserJet Color cartridges (~700 color composite (C/Y/M) yield); Installation guide; Printer documentation and software on CD-ROM; Power cord; USB cable

CONNECTIVITY
Ports
Hi-Speed USB 2.0 port; built-in fast Ethernet 10/100 Base-TX network port; 802.11n 2.4/5GHz wireless; Walkup host USB port

Wireless capability
Built-in 802.11 b/g/n; authentication via WEP, WPA/WPA2 or 802.11x; encryption via AES or TKIP; WPS; Wi-Fi Direct

Storage device and direct print support
Front-facing USB/Flash drive; USB printing

ENVIRONMENTAL
Acoustic power emissions
6.4 B(A) (color/simplex); 6.3 B(A) (mono/simplex); 6.3 B(A) (mono/duplex); 6.3 B(A) (color/duplex)

Operating humidity range
30 to 70% RH

Non-Operating humidity range
0 to 95% RH

Recommended operating temperature range (Celsius)
17 to 25ºC

Recommended operating temperature range (Fahrenheit)
63 to 77ºF

Storage temperature range (Celsius)
-20 to 40ºC

Storage temperature range (Fahrenheit)
-4 to 104ºF

Environmental specifications
Mercury-free

MEMORY
Memory
128 MB DDR, 128 MB NAND Flash
Maximum memory
128 MB DDR, 128 MB NAND Flash

MOBILE PRINTING CAPABILITY
Mobile printing services
HP ePrint; Apple AirPrint; Mopria-certified; Wireless Direct Printing; Mobile Apps

NETWORKING
Network protocols, supported
TCP/IP, IPv4, IPv6; Print: TCP-IP port 9100 Direct Mode, LPD (raw queue support only), Web Services Printing; Discovery: SLP, Bonjour, Web Services Discovery; IP Config: IPv4 (BootP, DHCP, AutoIP, Manual), IPv6

PAPER HANDLING
Input capacity
1-sheet in Tray 1; Up to 250 sheets (25 mm stack height) in Tray 2
Standard input capacity (envelopes)
Up to 15 mm (Recommended only 5 Envelopes or less at a time)
Output capacity
Up to 100 sheets (10 mm stack height)
Media sizes supported (metric)
Letter(216 x 280); Legal(216 x 356); Executive(184 x 267); Oficio 8.5×13(216 x 330); 4 x 6(102 x 152); 5 x 8(127 x 203); A4(210 x 299); A5(148 x 210); A6(105×148); B5(JIS)(182 x 257); B6(JIS)(128 x 182); 10x15cm(100 x 150); Oficio 216x340mm(216 x 340); 16K 195x270mm(195×270); 16K 184x260mm(184×260); 16K 197x273mm(197×273); Postcard(JIS)(100 x 147); Double Postcard(JIS)(147 x 200); Envelope #10(105 x 241); Envelope Monarch(98 x 191); Envelope B5(176 x 250); Envelope C5(162 x 229); Envelope DL(110 x 220); A5-R(210 x 148);
Media sizes supported (U.S. standard)
Letter(8.5 x 11); Legal(8.5 x 14); Executive(7.2 x 10.5); Oficio 8.5×13(8.5 x 13); 4 x 6(4 x 6); 5 x 8(5 x 8); A4(8.3 x 11.7); A5(5.8 x 8.3); A6(4.1 x 5.8); B5(JIS)(7.2 x 10.1); B6(JIS)(5 x 7.2); 10x15cm (3.9 x 5.9); Oficio 216×340 mm(8.5 x 13.4); 16K 195x270mm(7.6 x 10.6); 16K 184x260mm(7.2 x 10.2); 16K 197x273mm(7.8 x 10.7); Postcard (JIS)(3.9 x 5.8); Double Postcard(JIS)(5.8 x 7.9); Envelope #10(4.1 x 9.5); Envelope Monarch(3.9 x 7.5); Envelope B5(6.9 x 9.8); Envelope C5(6.4 x 9); Envelope DL(4.3 x 8.7); A5-R(8.3 x 5.8)
Media sizes, custom (metric)
76 x 127 to 216 x 356 mm
Media sizes, custom (U.S. standard)
3 x 5 to 8.5 x 14 in
Media types
Paper (bond, brochure, colored, glossy, heavy, letterhead, light, photo, plain, preprinted, prepunched, recycled, rough), transparencies, labels, envelopes, cardstock
Media weight supported (metric)
60 to 163 g/m² (Uncoated/Matte, recommended), however up to 175 g/m² Postcards and 200 g/m² HP Matte is allowed in the driver.
Media weight supported (U.S. standard)
16 to 42 lb (Uncoated/Matte, recommended), however up to 45 lb Postcards and 51 lb HP Matte is allowed in the driver.

PHYSICAL DIMENSIONS
Maximum dimensions (W x D x H, metric)
392 x 435 x 247.5 mm
Maximum dimensions (W x D x H, U.S. standard)
15.43 x 17.1 x 9.7 in
Weight (metric)
13.8 kg
Weight (U.S. standard)
30.4 lb

POWER
Energy savings feature technology
HP Auto-On/Auto-Off Technology; Instant-on Technology
Power supply type
Internal (Built-in) power supply
Power supply
110-volt input voltage: 110 to 127 VAC (+/- 10%), 50 Hz (+/- 3 Hz) , 60 Hz (+/- 3 Hz); 220-volt input voltage: 220 to 240 VAC (+/- 10%), 50 Hz (+/- 3 Hz), 60 Hz (+/- 3 Hz)(Not dual voltage, product varies by part number with # Option code identifier)
Power consumption
381 watts (active printing), 7.5 watts (ready), 0.8 watts (sleep), 0.1 watts (Manual-Off), 0.1 watts (Auto Off/Manual On), 0.8 watts (Auto Off/Wake on LAN)

PRINT CADTRIGES
Number of print cartridges
4 (1 each black, cyan, magenta, yellow)
Replacement cartridges
HP 202A Black LaserJet Toner Cartridge (~1400 yield) CF500A; HP 202A Cyan LaserJet Toner Cartridge (~1300 yield) CF501A; HP 202A Yellow LaserJet Toner Cartridge (~1300 yield) CF502A; HP 202A Magenta LaserJet Toner Cartridge (~1300 yield) CF503A; HP 202X Black LaserJet Toner Cartridge (~3200 yield) CF500X; HP 202X Cyan LaserJet Toner Cartridge (~2500 yield) CF501X; HP 202X Yellow LaserJet Toner Cartridge (~2500 yield) CF502X; HP 202X Magenta LaserJet Toner Cartridge (~2500 yield) CF503X; HP 203A Black LaserJet Toner Cartridge (~1400 yield) CF540A; HP 203A Cyan LaserJet Toner Cartridge (~1300 yield) CF541A; HP 203A Yellow LaserJet Toner Cartridge (~1300 yield) CF542A; HP 203A Magenta LaserJet Toner Cartridge (~1300 yield) CF543A; HP 203X Black LaserJet Toner Cartridge (~3200 yield) CF540X; HP 203X Cyan LaserJet Toner Cartridge (~2500 yield) CF541X; HP 203X Yellow LaserJet Toner Cartridge (~2500 yield) CF542X; HP 203X Magenta LaserJet Toner Cartridge (~2500 yield) CF543X
Replacement cartridges footnote
Replacement 202A and 203A cartridge average composite (C/Y/M) declared yield ~1300 and average black yield ~1400 pages; replacement 202X and 203X cartridge average composite (C/Y/M) declared yield ~2500 and average black yield ~3200 pages based on ISO/IEC 19798 and continuous printing. Actual yields vary considerably based on images printed and other factors.
HP SureSupply alerts you when your print cartridge is running low and helps you purchase online or locally through HP or a participating retailer.

PRINT SPECIFICATIONS
Print technology
Laser

Duplex printing
No

Print resolution (best)
Up to 600 x 600 dpi

Monthly duty cycle
Up to 40,000 pages

Print languages
HP PCL 6, HP PCL 5c, HP postscript level 3 emulation, PCLm, PDF, URF

Printer smart software features
Wireless printing, Ethernet networking, Wireless direct printing,HP ePrint, Apple AirPrint, Mopria-certified, Google Cloud Print, HP Auto-On/Auto-Off technology, HP Smart App, HP JetAdvantage Secure Print

REGULATORY SPECIFICATIONS
Regulatory model number
SHNGC-1600-01

Safety
EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; IEC 60950-1:2005 +A1:2009+A2:2013; EN 60825-1:2014 / IEC 60825-1:2014 (Class 1 Laser Product); EN 62479:2010 / IEC 62479:2010; CAN/CSA C22.2 No. 60950-1-07 2nd Ed.March 27, 2007 Compliance of IEC 60950-1 standard considers all country deviations according to the most recent IECEE CB Bulletin.; Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
Electromagnetic compatibility
CISPR 22:2008 & CISPR 32: 2012 /EN 55032:2012 – Class B; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 55024:2010; FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 6

SECURITY
Security management

Embedded Web Server: password-protection, secure browsing via SSL/TLS; Network: enable/disable network ports and features, SNMPv1 community password change; HP ePrint: HTTPS with certificate validation, HTTP Basic Access Authentication; Firewall and ACL; SNMPv3

SYSTEM REQUIREMENT
Minimum system requirements for Windows
Windows 10, 8, 7: 32-bit or 64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer. Windows Vista: (32-bit only), 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Windows XP SP3 or higher (32-bit only): any Intel Pentium II, Celeron or 233 MHz compatible processor, 850 MB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Windows Server support is provided via the command line installer and supports Win Server 2008 R2 and higher.
Minimum system requirements for Macintosh
Apple OS X Sierra(v10.12), El Capitan (v10.11), Yosemite (v10.10); 1.5 GB HD; Internet required; USB
Compatible network operating systems
Windows 10, 8, 7: 32-bit or 64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer. Windows Vista: (32-bit only), 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Windows XP SP3 or higher (32-bit only): any Intel Pentium II, Celeron or 233 MHz compatible processor, 850 MB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Windows Server support is provided via the command line installer and supports Win Server 2008 R2 and higher. Apple OS X: Sierra(v10.12), El Capitan (v10.11), Yosemite (v10.10); 1.5 GB HD; Internet required; USB. Linux (For more information, see http://hplipopensource.com/hplip-web/index.html). Unix (For more information, see http://www.hp.com/go/unixmodelscripts)
Operating system (supported note)
Not supportingWindows XP (64-bit) and Windows Vista (64-bit); Not all “Compatible Operating Systems” are supported with INBOX software; Full solution software available only for Windows 7 and newer; Legacy Windows Operation Systems (XP, Vista, and equivalent servers) get print drivers only; Windows Server OS install driver only; Windows RT OS for Tablets (32 & 64-bit) uses a simplified HP print driver built into the RT OS; Linux systems use in-OS HPLIP software
Warranty
Warranty
One-year limited hardware warranty
